유니티 쉐이더 - 쉐이더그래프/앰플리파이 쉐이더에서의 커스터 버택스 스트림 사용



유니티 쉐이더 - 쉐이더그래프/앰플리파이 쉐이더에서의 커스터 버택스 스트림 사용

금별 0 851 2019.08.20 03:33

99798B435D5AEB24055781

998FC9445D5AEB9E0586B6

9996424D5D5AEBE805FA75





One simple way is setting your colors as HDR in shadergraph

998EA74D5D5AEC5206003F



and use AgePercent to Lerp between the color



998E4F4D5D5AEC550669E1



The only counterpart is if you want 4 different colors over the particule life, you will have to declare 4 colors :



998EC44D5D5AEC5806FA79





Here the result :





In few words, each smoothstep provide a [0-1] value to lerp between the different colors.
The smoothstep range is define by [1 / 3 (numberOfSmoothstep)]



  • for the first one you have [0 => 0.33]
  • the seconde one : [0.33 => 0.33 * 2]
  • the last one : [0.33 * 2 => 0.33 * 3]



I hope it’s what you’re looking for in a way!
And here the shader for example (you can see the setup for shuriken in the gif). Sorry, i don’t know how to add commentary in shadergraph… and it’s look like it’s impossible for the moment!



다운로드

https://drive.google.com/file/d/19oafzIyZIg3qzvszjFwKc0z7ZHYOiPUZ/view





Ok, so here is what I have:

993A4B395D5AEDC2058993



Pretty basic, i just want to influence the alpha.

Now I want to join a noise with it, a multiply should be enough:



993A73395D5AEDC405ACA9



Here is the result:



99F4ED3C5D5AED8B053DEC



And here is the setting for the particle system



99F6183C5D5AED8D055099



It completely ignores any values put on the custom data. But if I remove UV (TXCOORD0.xy)



99F6743C5D5AED8F05F867





Well, it works ! Buuuut now it loses its ability to read the texture.

If it isn’t clear enough please tell me ! And thank you for dedicating time for newbies like me <3
